12. OVERSCALE/ERROR DISPLAYS
12-1. Overscale Display
12-2. Calibration Error Display
Minus overflow of the A/D converter （under -3.2mV/V between ± SIG）
Plus overflow of the A/D converter （over 3.2mV/V between ± SIG）
Indicated value overflowed （indicated value<-1999）
Indicated value overflowed （indicated value>1999）
Span set value is "00000"
Output of the strain gauge sensor does not reach the span
Output of the strain gauge sensor is on the minus（negative）side.
adjustment range.
