Teac TD-240A - Indicator Section

15.SPECIFICATIONS
86
15-2. Indicator Section
Indicator Numeric display （5 digits）, 15mm in height, red LED
Numeric 5digits ±
Indicatid value － 19999 to 19999
Decimal point Selectable
Items Status HI，OK，LOW，PEAK，HOLD
Red LED 5
Count 3，6，13，25times/sec. Selectable
15-3. Setting Section
Items Calibration：Zero/Span calibration （actual load calibration,
equivalent input calibration）
High limit value，Low limit value，High/Low limit comparison mode，
Hysteresis, Digital offset, Near zero，Digital filter, Analogfilter，
Motion detect, Zero tracking, Hold mode，Automatic printing，
Hold value printing，LOCK，Scale division，Display frequency,
Excitation Voltage，BCD data update rate，RS-232C，D/A converter
setting，D/A converter fullscael setting.
15-4. External Signals
High limit relay，Low limit relay，Analog voltage output，
Hold signal input, Digital zero signal input.
15-5. Interface
SI/F output
