TERMINAL CONNECTION TABLE SETTING (Submode 69)
This submode is required for in-line services. Enter the In-line ID No. and the Register No. of each terminal
(including the Master Terminal) connected to the in-line cable.
CONDITION Any time outside a sale
OPERATION Mode Lock: SET and IN-LINE Lamp illuminated
69 [X] |In-line ID No.| [ST] |Register No.| [#] [AT/TL]
* For sequentially
programming In-
line ID Nos, the In-
line ID specification
can be skipped.
➤
0 to 999999
(NOTE 2 below)
1 to 6
(NOTES 1 & 2 below)
Repeat for other terminals to be connected, including the Master Terminal
itself. (Max. 16 terminals for the Scanning System Type or PLU Manual
Entry System Type, including the Master Terminal.)
➤
➤
➤
➤
*
........
........
NOTES: 1. In-line ID No.: Master Terminal ... 1 (fixed)
Backup Master Terminal (if connected) ... 2 (fixed)
Satellite Terminals ... 3 to 16 (max. 14 terminals)
2. The In-line ID No. and Register No. of each terminal to be set here must be the same as those
programmed for the terminal in IN-LINE TERMINAL ID SETTING (Submode 77) and STORE/
REGISTER NO. SETTING (no submode) in Chapter 7 of the Programming Manual for stand-
alone level.
3. To delete an individual terminal from the Terminal Connection Table, enter 0 in place of the In-
line ID No. in the above operation pattern.
4. To delete the entire Terminal Connection Table once set, operate:
69 [X] → 0 [AT/TL]
5. If a deleting operation (individual or entire deletion) is performed, the files occupied by the deleted
terminal(s) (such as Floating Cashier File, etc.) is canceled. Therefore, a deleting operation
should be performed only when the system is to be re-built or a terminal is to be detached from
the system.
ex.) To set Master Terminal and a Satellite Terminal in the connection table
(total of two terminals in the in-line system):
Master Terminal ID No. 1 Register No. 111101
Satellite Terminal ID No. 3 Register No. 333303
Mode Lock: SET / and IN-LINE Lamp illuminated
69 [X]
1 [ST]111101 [#] (for the Master Terminal)
3 [ST]333303 [#] (for the Satellite Terminal)
[AT/TL]
