3. DIAGNOSTIC TEST OPERATION EO18-11006A
3.10 Drawer Open Test
3-10
3.10 Drawer Open Test
(1) Contents
All drawers which are connected to the ECR are opened.
(2) Operation
Mode Lock: BLIND
Key Operation: 80 [X] (or [@/FOR]) 15 [AT/TL]
(3) Print format
(4) Display
• LCD display (2nd line)
• 7-segment display
∗ When a drawer is opened, the corresponding drawer No. is displayed.
∗ The drawer No. goes off when the drawer is closed.
∗ The drawers are opened in the order of drawer 1 and drawer 2 at one second interval.
(5) Quit
The test ends by pressing the [ITEM CORR] key or by closing the drawer.
NOTES:
1. When the power is turned OFF during the test, it will be resumed at the power on time unless the Mode Lock
position is “BLIND”.
2. When no drawer is connected or the connected drawer does not support the drawer compulsory function,
the drawer status is always “Open” regardless of the actual drawer status.
10-31-2005 MON #0
P80
DIAG 15
0012 15:48TM
Store Name Logo
Drawer No. 2
Drawer No. 1
D 1
To Next Page
