TEC MA-600 Series Maintenance Manual

6. MAIN UNIT REPLACEMENT EO18-11006A
6.5 Replacing the FIU PC Board Ass’y
6- 9
5) Release the two hooks which secure the FIU PC Board Ass’y.
6) Replace the FIU PC Board Ass’y with a new one, and then reassemble in the reverse order of removal.
7) Make a display test in the diagnostic test to check the operation of the new FIU PC Board Ass’y. (Refer to
Section 3.3 Display Test.)
Hook
FIU PC Board Ass’y
FIU PC Board Ass’y
