6. MAIN UNIT
REPLACEMENT
EO18-11006A
6.8 Replacing the Keyboard Unit
6-15
4)
Replace the Keyboard Unit with a new one, and t
hen reassemble in the reverse order of removal.
5)
Make a keyboard test in the diagnostic test to check the operation of the new Keyboard Unit. (Refer to
Section 3.9 Keyboard Test
.)
44
46
