8.6.1 General Description of the Manifold
The HYDROFLEX PLUS is delivered with the manifold already installed.
The instrument can be used with the following types of manifolds:
• Standard 8-way and
• Standard 16-way
The manifolds for the HYDROFLEX PLUS have the same basic components:
Fig. 8.1 The Rear of the Manifold
Note
Always wear powder free gloves when handling the manifold.
Dispensing Tubes
Locating Pin
Aspirating Tubes
Locating Pin
