I Hardware Installation Manual 4. System Hardware
43
The robot stick is magnetic so that it can be attached to magnetic surfaces. However, the risk of
falling or rotating caused by poor attachment should be taken into account. It is recommended
using the official Robot Stick Stand (official accessasory) to secure the robot stick. In that case,
the Robot Stick Stand should be fixed with screws. Do not freely place the robot stick when it is
not fixed. The robot stick should be placed in a way that the signal cables are routed properly to
avoid damage caused by pulling.
1. The control box, cables, power signal cables, and robot stick cannot be used when any of
them is in contact with liquids. This may result in personal injury or death.
2.
The control box has an IP20 rating so that it cannot be used in environments with powder and
moisture. Particular attention should be paid to environments with conductive dust (such as
metal swarf).
Note
Danger
