MediaGateway User Manual
3.6.1.3 S1-P4 (CPU) and internal ports (P4 and P8)
Figure 3-18: CPU port and internal ports
Port name: Here you can change the Port Name
Tx octets: decimal value of sent octets on this port.
Rx octets: decimal value of received octets on this port.
Prevent Sleep Port: This option is available if the function “Prevent sleep” on “Control
panel” tab is deactivated.
This port is monitored: If on this port is incoming traffic, the MediaGateway
doesn’t fall asleep.
This port is not monitored: The MediaGateway can fall asleep, even if there is
incoming traffic on this port.
Mirroring: Here you can choose the incoming traffic from the ports, which you want to
be mirrored to this port. It is for each switch only for one port available.
