MediaGateway User Manual
Drop ingress packets with…:
Source IP: one IP address can be configured here. It is a filter for incoming traffic. Data
with configured IP address as source IP address will be dropped and not forwarded,
when incoming on this port.
Destination IP: one IP address can be configured here. It is a filter for incoming traffic.
Data with configured IP address as destination IP address will be dropped and not
forwarded.
Redirect packets to…: By defining an Ethernet port (or the SFP-slot) you can redirect
packets with a specific destination IP address to this port, independent from any other
configuration. It means, that the packet is not sent to the port it was originally
supposed to be sent. This function is only available for IP layer.
3.6.2 Port Information while Single VLAN tagging is active
If IEEE 802.1q (VLAN) mode is hooked (see CHAPTER 3.5.1) but not double tagging,
port based single VLAN is activated.
In this mode, the routing through the MediaGateway is defined by the configuration of
each port.
Grey fields are not configurable and have standard values or no values.
