MediaGateway User Manual
Service ID UINT16 0x0124
Method ID UINT16 Dependent from used method
Length UINT32 0x8 + size of payload
Request ID UINT32 0x00000000
Protocol Version UINT8 0x01
Interface version UINT8 0x01
Message Type UINT8 0x00
Return Code UINT8 0x00
Payload Variable size Dependent from used method
Table 7-2: Detailed Information in SOME/IP Header
The blue text modules are different for each method for remote control of the
MediaGateway. All other values are always the same.
7.1 Reset Device
This method performs a complete device reset. The configuration after a device restart
is loaded from flash.
Request with:
Method ID: 0x0001
Length: 0x8
Payload: no payload
Response:
This method returns a SOME/IP message with return code 0x00 (OK) before restart.
7.2 Import Configuration
This method has the same behaviour as the Import button from webpage of the
MediaGateway. This method stores a configuration into the flash. The new
configuration is the payload.
Note: New settings will be applied when next device restart is performed.
Request with:
Method ID: 0x0002
Length: 0x8 + count of bytes of payload
