MediaGateway User Manual

1 2

100BASE-T1 Port selection Enable/disable

Field Name

Data Type

Description

100BASE-T1 Port selection UINT8 0x00: S1-P0

0x01: S1-P1

0x02: S1-P2

0x03: S1-P3

0x04: S2-P0

0x05: S2-P1

0x06: S2-P2

0x07: S2-P3

0x08: S3-P0

0x09: S3-P1

0x0A: S3-P2

0x0B: S3-P3

Enable/disable UINT8 0x00 for disable

0x01 for enable

Response:

This method returns a SOME/IP message with return code 0x00 (OK).

7.9 Set Port to Master/Slave (only 100BASE-T1-Ports)

Via this method the user can set 100BASE-T1 ports to master or slave,similarly to the

BroadR-Reach® mode function on the webserver for the 100BASE-T1 ports.

Request with:

Method ID: 0x0009

Length: 0xA

Payload: 2 bytes contain the information, which port is set to master/slave.

2 Byte

1 2

100BASE-T1 Port selection BroadR-Reach® mode

Technica MediaGateway User Manual
