Technicolor DWA0120 User Manual

10
1 Getting started
DMS3-CTC-25-552 v1.0
Broadband LED (if you are using the DSL gateway scenario)
Broadband LED (if you are using the local router scenario)
Internet LED
Wireless LED
WPS LED
For more information about WPS, see “3.1.1 Connecting to the Wi-Fi using WPS” on page 22.
Colour State Description
Green Solid on DSL line synchronised.
Blinking Trying to detect carrier signal or pending DSL line synchronisation.
Off No DSL line connected.
- or -
Your DWA0120 powered off.
Colour State Description
Green Solid on Connected to the WAN device.
Off Not connected to the WAN device.
Colour State Description
Green Solid on Connected to the Internet, no activity.
Blinking Connected to the Internet, sending/receiving data.
Red Blinking Trying to connect to the Internet.
Off No Internet connection.
Colour State Description
Green Solid on At least one device is connected to the Wi-Fi access point, no wireless
activity.
Blinking At least one device is connected to the Wi-Fi access point and traffic is
present.
Off No devices connected to the Wi-Fi access point or Wi-Fi is disabled.
Both the 2.4 GHz and 5 GHz Wi-Fi access point have a dedicated Wireless LED.
Colour State Description
Green Solid On Client successfully registered via WPS.
Orange Blinking WPS registration ongoing.
Red Blinking Error occurred.

Technicolor DWA0120 Specifications

General

Device Type	Gateway
Wireless Technology	Wi-Fi
Frequency Band	2.4 GHz
Maximum Data Rate	300 Mbps
Ethernet Ports	4 x 10/100 Mbps
Antenna	Internal
Wireless Standards	802.11 b/g/n
Security Features	WPA2
Ports	4 Ethernet, 1 USB
