Technicolor DWA0120 User Manual

65
5 Content and Printer Sharing
DMS3-CTC-25-552 v1.0
5.2.3 Installing the printer on your computer
How to install a printer on Windows
Proceed as follows:
1 Make sure that your computer is connected to the DWA0120.
2 Open (File) Explorer and then click Network.
3 The Network window appears. Double-click Technicolor.
4 Your printer should now appear.
Double-click your printer.
5 Windows prompts you that it could not find a driver. Click OK.
6 Follow the instruction from Windows to select or install the correct driver.
You can also access the device by entering \\192.168.1.1 in the address bar.

Technicolor DWA0120 Specifications

General

Device Type	Gateway
Wireless Technology	Wi-Fi
Frequency Band	2.4 GHz
Maximum Data Rate	300 Mbps
Ethernet Ports	4 x 10/100 Mbps
Antenna	Internal
Wireless Standards	802.11 b/g/n
Security Features	WPA2
Ports	4 Ethernet, 1 USB
