Technicolor DWA0120 User Manual

8
1 Getting started
DMS3-CTC-25-552 v1.0
1.2.4 Buttons
Overview
Power button
The Power ( ) button allows you turn your DWA0120 on or off.
Info button
The Info ( ) button has two functions:
• The integrated LED indicates the overall status of the DWA0120 services.
•Pressing the Info button will temporarily enable the status LEDs when they are disabled.
For more information, see “1.2.5 LEDs” on page 9.
Wi-Fi On/Off button
The Wi-Fi On/Off ( ) button allows you to manually disable the Wi-Fi of your DWA0120. You can do this when none of
your devices is using the Wi-Fi network.
To turn the Wi-Fi on or off, briefly press and hold the Wi-Fi On/Off button for at least five seconds.
WPS button
The WPS ( ) button allows you to add new Wi-Fi clients to your network in an easy yet secure way without the need to
enter any of your wireless settings manually.
For more information, see “3.1.1 Connecting to the Wi-Fi using WPS” on page 22.
Reset button
The recessed Reset button allows you to reset your DWA0120 to factory defaults.
For more information, see “7.4 Reset to factory defaults” on page 76.
WPS
Reset
To know whether the Wi-Fi access point is enabled or not, check the Wireless LEDs.
For more information see “Wireless LED” on page 10.

Technicolor DWA0120 Specifications

General

Device Type	Gateway
Wireless Technology	Wi-Fi
Frequency Band	2.4 GHz
Maximum Data Rate	300 Mbps
Ethernet Ports	4 x 10/100 Mbps
Antenna	Internal
Wireless Standards	802.11 b/g/n
Security Features	WPA2
Ports	4 Ethernet, 1 USB
