23
3Wi-Fi
DMS3-CTC-25-552 v1.0
Connect your Wi-Fi client using WPS PBC
Proceed as follows:
1 Briefly press the WPS button on your DWA0120:
2 The WPS LED starts blinking orange. This indicates that your DWA0120 is now searching for Wi-Fi clients that are in
registration mode. You now have two minutes to start WPS on your Wi-Fi client.
3 Start WPS PBC on your Wi-Fi client.
4 Your DWA0120 provides its wireless settings to the Wi-Fi client.
5 At the end of the WPS process, the status of the WPS LED on your DWA0120 will change to either of the following:
Solid green
This indicates that you successfully registered and connected this Wi-Fi client. You are now connected to your
DWA0120 wireless network.
Blinking red
This indicates that your DWA0120 could not find any Wi-Fi client in WPS pairing mode or that the exchange of the
wireless settings and/or registration failed. For more information, see “Cannot connect via WPS” on page 74.
Connect your Wi-Fi client using WPS PIN code entry on the Wi-Fi client
Proceed as follows:
1 Check the label on your DWA0120 and note the following information:
For each Wi-Fi access point, a PIN code that is printed next to the WPS logo.
The Network Name.
These are the default values. If you already changed these settings, use the new settings instead.
2 Go to the WPS PIN code entry page of your Wi-Fi client. Consult the documentation of your Wi-Fi client for more
information.
3 Enter the PIN code,
4 Your Wi-Fi client may prompt you to select your Wi-Fi access point. If this is the case, your Wi-Fi access point will be
listed with its Network Name.
Make sure that you know how to start WPS on your Wi-Fi client before you start. Consult the documentation of
your Wi-Fi client for more information.
WPS
Do not include the hyphen when entering the PIN code. For example, if the PIN code is 1234-5678, then enter
12345678.
You can find the default network name on the label on your DWA0120.
