RUN PERSONAL: Service & maintenance manual - rev. 3.1
Page 7.15
Figure 7.5-10
4. Back off the 9 screws (a)
Phillips screwdriver.
5. Remove the CPU Board (F).
Figure 7.5-11
Headphone Jack (G):
1. Back off the 2 screws (a)
Phillips screwdriver.
2. Disconnect the cable from the CPU board.
3. Remove the Headphone Jack (G).
To reassemble the Electronics Boards,
carry out the above steps in reverse order.
