© Technosoft 2007 15 IBL2403 Technical Reference
Others
Min. Typ. Max. Units
Operating 0 40
°C
Temperature
Storage (not powered) -40 85
°C
Operating 0 90 %RH
Humidity (Non-condensing)
Storage 0 100 %RH
Altitude (referenced to sea level) 0 ÷ 1 +4 Km
Altitude / pressure
12
Ambient Pressure 0.64 0.9 ÷ 1 4.0 atm
Dimensions Length x Width x Height 65 x 58 x 19 mm
Weight 0.1 Kg
Protection degree IP20 (according to IEC529)
1
“FS” stands for “Full Scale”
†
Stresses beyond values listed under “absolute maximum ratings” may cause permanent damage to the device.
Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
T.B.D. = To be determined
Figure 2.12. De-rating with ambient temperature
13
14
Figure 2.13. De-rating with altitude
12
At altitudes over 1,000m, current and power rating are reduced due to thermal dissipation efficiency at higher altitudes.
See Figure 2.13 – De-rating with altitude
13
I
NOM
– the nominal current
14
Stand-alone operation, vertical mounting
