© Technosoft 2007 32 IBL2403 Technical Reference
3.2.9.4 Linear Hall connection
5
GND
+3.3V
B- / LH2
C- / LH3
14
Linear Hall connection
IBL2403
v1.1
MotionChip
TM
+5V
OUT
J2
12
+5V
Internally
generated
3 x 10K
3 x 20K
3 x 22nF
13
A- / LH1
Figure 3.18. Linear Hall connection
