TD350 Series VFD Function parameter list
-147-
Function
code
Name
Detailed parameter description
Default
value
Modify
12: Reserved
Note: Source 1-11, 100% relative to the max.
frequency
P03.16
Keypad limit
value of upper
limit frequency of
forward rotation
in torque control
This function code is used to set frequency limit.
100% corresponds to the max. frequency. P03.16
sets the value when P03.14=1; P03.17 sets the
value when P03.15=1.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
60.00H
z
○
P03.17
Max. output
frequency
60.00H
z
○
P03.18
Source of upper
limit setting of the
torque during
motoring
0: Keypad (P03.20)
1: AI1 (100% relative to three times of motor
current)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: Modbus/Modbus TCP communication (the same
as above)
6: PROFIBUS/CANopen/DeviceNet communication
(the same as above)
7: Ethernet communication (the same as above)
8: Pulse frequency HDIB (the same as above)
9: EtherCAT/PROFINET/Ethernet IP
communication
10: PLC
11: Reserved
0
○
P03.19
Source of upper
limit setting of
brake torque
0: Keypad (P03.21)
1: AI1 (100% relative to three times of motor
current)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: Modbus/Modbus TCP communication (the same
as above)
6: PROFIBUS/CANopen/DeviceNet communication
(the same as above)
7: Ethernet communication (the same as above)
8: Pulse frequency HDIB (the same as above)
9: EtherCAT/PROFINET/Ethernet IP
0
○
