TECHTOP TD350 - Page 163

TD350 Series VFD Function parameter list
-158-
Function
code
Name
Detailed parameter description
Default
value
Modify
P04.48
Integral
coefficient in IF
mode for
asynchronous
motor 2
When IF control is adopted for asynchronous motor
2, this parameter is used to set the integral
coefficient of the output current closed-loop control.
Setting range: 0–5000
350
○
P04.49
Frequency
threshold for
switching off IF
mode for
asynchronous
motor 2
When IF control is adopted for asynchronous motor
2, this parameter is used to set the frequency
threshold for switching off the output current
closed-loop control. When the frequency is lower
than the value of this parameter, the current
closed-loop control in the IF control mode is
enabled; and when the frequency is higher than
that, the current closed-loop control in the IF control
mode is disabled.
Setting range: 0.00–20.00 Hz
10.00H
z
○
P04.50
Reserved
variable
0–65535
0
●
P04.51
Reserved
variable
0–65535
0
●
P05 group Input terminals
P05.00
HDI input type
0x00–0x11
Ones: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0
◎
P05.01
Function of S1
terminal
0: No function
1: Forward running
2: Reverse running
3: 3-wire control/Sin
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Running pause
9: External fault input
1
◎
P05.02
Function of S2
terminal
4
◎
P05.03
Function of S3
terminal
7
◎
P05.04
Function of S4
terminal
0
◎
P05.05
Function of HDIA
terminal
0
◎
