TD350 Series VFD Function parameter list
-168-
Function
code
Name
Detailed parameter description
Default
value
Modify
30: Positioning completed
31: Spindle zeroing completed
32: Spindle scale-division completed
33: In speed limit
34: Virtual terminal output of
EtherCAT/PROFINET/Ethernet IP communication
35: Reserved
36: Speed/position control switch-over completed
37:Arbitrary freq arrival
38–40: Reserved
41: C_Y1 from PLC (You need to set P27.00 to 1.)
42: C_Y2 from PLC (You need to set P27.00 to 1.)
43: C_HDO from PLC (You need to set P27.00 to
1.)
44: C_RO1 from PLC (You need to set P27.00 to 1.)
45: C_RO2 from PLC (You need to set P27.00 to 1.)
46: C_RO3 from PLC (You need to set P27.00 to 1.)
47: C_RO4 from PLC (You need to set P27.00 to 1.)
48:PT100 temperature pre-alarm
49:PT1000 temperature pre-alarm
50: Triggered by S1 input
51: Triggered by S2 input
52: Triggered by S3 input
53: Triggered by S4 input
54: Triggered by Sx terminal
55: Triggered by Sx terminal
56–63: Reserved
P06.05
Output terminal
polarity selection
This function code is used to set the polarity of
output terminals.
When the bit is set to 0, input terminal polarity is
positive;
When the bit is set to 1 input terminal polarity is
negative.
BIT3
BIT2
BIT1
BIT0
RO2
RO1
HDO
Y
Setting range: 0x0–0xF
00
○
P06.06
Y switch-on delay
This function code defines the corresponding delay
of the level variation from switch-on to switch-off.
0.000s
○
P06.07
Y switch-off delay
0.000s
○
