TECHTOP TD350 - Page 174

TD350 Series VFD Function parameter list
-169-
Function
code
Name
Detailed parameter description
Default
value
Modify
P06.08
HDO switch-on
delay
Y electric level
Y valid
Invalid
Switch on
delay
invalid
Valid
Switch off
delay
Setting range: 0.000–50.000s
Note: P06.08 and P06.09 are valid only when
P06.00=1.
0.000s
○
P06.09
HDO switch-off
delay
0.000s
○
P06.10
Relay RO1
switch-on delay
0.000s
○
P06.11
Relay RO1
switch-off delay
0.000s
○
P06.12
Relay RO2
switch-on delay
0.000s
○
P06.13
Relay RO2
switch-off delay
0.000s
○
P06.14
AO1 output
selection
0: Running frequency
1: Set frequency
2: Ramps reference frequency
3: Running speed
4: Output current (relative to 2 times the rated
current of the VFD)
5: Output current (relative to 2 times the rated
current of the motor)
6: Output voltage (relative to 1.5 times the rated
voltage of the VFD)
7: Output power (relative to 2 times the rated power
of the motor)
8: Set torque value (relative to 2 times the rated
torque of the motor)
9: Output torque (relative to 2 times the rated torque
of the motor)
10: Analog AI1 input value
11: Analog AI2 input value
12: Analog AI3 input value
13: Input value of high-speed pulse HDIA
14: Set value 1 of Modbus/Modbus TCP
communication
15: Set value 2 of Modbus/Modbus TCP
communication
16: Set value 1 of PROFIBUS/CANopen/DeviceNet
communication
17: Set value 2 of PROFIBUS/CANopen/DeviceNet
0
○
P06.15
Reserved
variables
0
○
P06.16
HDO high-speed
pulse output
0
○
