TD350 Series VFD Function parameter list
-204-
Function
code
Name
Detailed parameter description
Default
value
Modify
extension card in
card slot 1
P16.28
Communication
timeout period of
extension card in
card slot 2
0.0–600.0s
If it is set to 0.0, offline fault will not be detected
0.0s
/
P16.29
Communication
timeout period of
extension card in
card slot 3
0.0–600.0s
If it is set to 0.0, offline fault will not be detected
0.0s
/
P16.54
EtherNet IP
communication
timeout
0.5–60.0s
0.5s
◎
P16.55
EtherNet IP
communication
rate setting
0: Self-adaption
1: 100M full duplex
2: 100M half duplex
3: 10M full duplex
4: 10M half duplex
0
◎
P16.56
EtherNet IP
control word
definition
method
0: Decimal
1: Binary
0
◎
P16.30–
P16.69
See the operation manual of communication extension card for details
P17 group State-check functions
P17.00
Set frequency
Display current set frequency of the VFD.
Range: 0.00Hz–P00.03
50.00H
z
●
P17.01
Output frequency
Display current output frequency of the VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.02
Ramps reference
frequency
Display current ramps reference frequency of the
VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.03
Output voltage
Display current output voltage of the VFD.
Range: 0–1200V
0V
●
P17.04
Output current
Display the valid value of current output current of
the VFD.
Range: 0.0–5000.0A
0.0A
●
