TECHTOP TD350 - Page 210

TD350 Series VFD Function parameter list
-205-
Function
code
Name
Detailed parameter description
Default
value
Modify
P17.05
Motor speed
Display current motor speed.
Range: 0–65535RPM
0 RPM
●
P17.06
Torque current
Display current torque current of the VFD.
Range: -3000.0–3000.0A
0.0A
●
P17.07
Exciting current
Display current exciting current of the VFD.
Range: -3000.0–3000.0A
0.0A
●
P17.08
Motor power
Display current motor power; 100% relative to rated
motor power, positive value is motoring state,
negative value is generating state.
Range: -300.0–300.0% (relative to rated motor
power)
0.0%
●
P17.09
Motor output
torque
Display current output torque of the VFD; 100%
relative to rated motor torque, during forward
running, positive value is motoring state, negative
value is generating state, during reverse running,
positive value is generating state, negative value is
motoring state.
Range: -250.0–250.0%
0.0%
●
P17.10
Estimated motor
frequency
The estimated motor rotor frequency under
open-loop vector condition.
Range: 0.00– P00.03
0.00Hz
●
P17.11
DC bus voltage
Display current DC bus voltage of the VFD.
Range: 0.0–2000.0V
0V
●
P17.12
Digital input
terminal state
Display current digital input terminal state of the
VFD.
0000–003F
Corresponds to HDIB, HDIA, S4, S3, S2 and S1
respectively
0
●
P17.13
Digital output
terminal state
Display current digital output terminal state of the
VFD.
0000–000F
Corresponds to R02, RO1, HDO and Y1
respectively
0
●
P17.14
Digital
adjustment
variable
Display the regulating variable by UP/DOWN
terminals of the VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.15
Torque reference
value
Relative to percentage of the rated torque of current
motor, display torque reference.
Range: -300.0%–300.0% (rated motor current)
0.0%
●
