TD350 Series VFD Function parameter list
-224-
Function
code
Name
Detailed parameter description
Default
value
Modify
Bit9: Positioning completion signal selection
0: Electric level signal
1: Pulse signal
Bit10: Z pulse signal source
0: Motor
1: Spindle
Bit11–15: Reserved
P22.01
Speed of spindle
orientation
During spindle orientation, the speed of the position
point of orientation will be searched, and then it will
switch over to position control orientation.
Setting range: 0.00–100.00Hz
10.00H
z
○
P22.02
Deceleration time
of spindle
orientation
Deceleration time of spindle orientation.
Spindle orientation deceleration time means the
time needed for the VFD to decelerate from Max.
output frequency (P00.03) to 0Hz.
Setting range: 0.0–100.0s
3.0s
○
P22.03
Spindle zeroing
position 0
Users can select the zeroing positions of four
spindles by terminals (function code 46, 47).
Setting range: 0–39999
0
○
P22.04
Spindle zeroing
position 1
Setting range: 0–39999
0
○
P22.05
Spindle zeroing
position 2
Setting range: 0–39999
0
○
P22.06
Spindle zeroing
position 3
Setting range: 0–39999
0
○
P22.07
Spindle
scale-division
angle 1
Users can select seven spindle scale-division
values by terminals (function code 48, 49 and 50).
Setting range: 0.00–359.99
15.00
○
P22.08
Spindle
scale-division
angle 2
Setting range: 0.00–359.99
30.00
○
P22.09
Spindle
scale-division
angle 3
Setting range: 0.00–359.99
45.00
○
P22.10
Spindle
scale-division
angle 4
Setting range: 0.00–359.99
60.00
○
