TD350 Series VFD Function parameter list
-225-
Function
code
Name
Detailed parameter description
Default
value
Modify
P22.11
Spindle
scale-division
angle 5
Setting range: 0.00–359.99
90.00
○
P22.12
Spindle
scale-division
angle 6
Setting range: 0.00–359.99
120.00
○
P22.13
Spindle
scale-division
angle 7
Setting range: 0.00–359.99
180.00
○
P22.14
Spindle drive
ratio
This function code sets the reduction ratio of the
spindle and the mounting shaft of the encoder.
Setting range: 0.000–30.000
1.000
○
P22.15
Zero-point
communication
setting of spindle
P22.15 sets spindle zero-point offset, if the selected
spindle zero point is P22.03, the final spindle zero
point will be the sum of P22.03 and P22.15.
Setting range: 0–39999
0
○
P22.16
Reserved
variables
0–65535
0
○
P22.17
Reserved
variables
0–65535
0
○
P22.18
Rigid tapping
selection
Ones: Enable/disable
0: Disable
1: Enable
Tens: Analog port selection
0: Invalid
1: AI1
2: AI2
3: AI3
0x00
◎
P22.19
Analog filter time
of rigid tapping
0.0ms–1000.0ms
1.0ms
○
P22.20
Max. frequency
of rigid tapping
0.00–400.00Hz
50.00H
z
○
P22.21
Corresponding
frequency of
analog zero drift
of rigid tapping
0.00–10.00Hz
0.00Hz
○
P22.22
Reserved
variables
0–1
0
○
