TD350 Series VFD Function parameter list
-231-
Function
code
Name
Detailed parameter description
Default
value
Modify
P24.22
Switch-over
frequency
threshold of
speed
measurement
mode
0–630.00Hz
1.00Hz
○
P24.23
Synchronous
motor angle
compensation
coefficient
-200.0–+200.0%
100.0%
○
P24.24
Reserved
variables
0–65535
0
○
P25 group Extension I/O card input functions
P25.00
HDI3 input type
selection
0: HDI3 is high-speed pulse input
1: HDI3 is digital input
0
◎
P25.01
S5 terminal
function
The same with P05 group
0
◎
P25.02
S6 terminal
function
0
◎
P25.03
S7 terminal
function
0
◎
P25.04
S8 terminal
function
0
◎
P25.05
S9 terminal
function
0
◎
P25.06
S10 terminal
function
0
◎
P25.07
HDI3 terminal
function
0
◎
P25.08
Input terminal
polarity of
extension card
0x00–0x7F
0x00
○
P25.09
Virtual terminal
setting of
extension card
0x000–0x7F (0: disable, 1: enable)
BIT0: S5 virtual terminal
BIT1: S6 virtual terminal
BIT2: S7 virtual terminal
BIT3: S8 virtual terminal
BIT4: S9 virtual terminal
0x00
◎
