TD350 Series VFD Extension cards
-292-
Name
Model
Specification
PROFIBUS-DP
communication card
EC-TX503
 Supporting the PROFIBUS-DP protocol
Ethernet
communication card
EC-TX504
 Supporting Ethernet communication with
TECHTOP's internal protocol
 Can be used in combination with TECHTOP's upper
computer monitoring software TECHTOP Studio
CANopen
communication card
EC-TX505
 Based on the CAN2.0A physical layer
 Supporting the CANopen protocol
PROFINET
communication card
EC-TX509
 Supporting the PROFINET protocol
Ethernet/IP
communication card
EC-TX510
 Supporting the Ethernet IP protocol and ODVA
protocol
 With two Ethernet IP ports, supporting 10/100M
half/full duplex operating
 Supporting star, line, and ring network topologies
(but not supporting ring network monitoring)
CAN master/slave
control
communication card
EC-TX511
 Based on the CAN2.0B physical layer
 Adopting TECHTOP's master-slave control
proprietary protocol
Sin/Cos PG card
EC-PG502
 Applicable to Sin/Cos encoders with or without CD
signals
 Supporting A, B, Z frequency-divided output
 Supporting input of pulse string reference
UVW incremental
PG card
EC-PG503-05
 Applicable to 5V differential encoders
 Supporting A, B, Z orthogonal input
 Supporting U, V, W 3PH pulse input
 Supporting A, B, Z frequency-divided output
 Supporting input of pulse string reference
Resolver PG card
EC-PG504-00
 Applicable to resolver encoders
 Supporting simulated A, B, Z frequency-divided
output of resolvers
 Supporting input of pulse string reference
Multi-function
incremental PG card
EC-PG505-12
 Applicable to OC encoders of 5 V or 12 V
 Applicable to push-pull encoders of 5 V or 12 V
 Applicable to differential encoders of 5 V
 Supporting the orthogonal input of A, B, and Z
 Supporting the frequency-divided output of A, B, and
Z
 Supporting pulse string setting
