TECHTOP TD350 - IO Extension Card (EC-IO501-00) Function Description

TD350 Series VFD Extension cards
-293-
Name
Model
Specification
24V incremental PG
card
EC-PG505-24
 Applicable to 24V OC encoders
 Applicable to 24 V push-pull encoders
 Applicable to 5 V differential encoders
 Supporting A, B, Z orthogonal input
 Supporting A, B, Z frequency-divided output
 Supporting pulse string reference input
Simple incremental
PG card
EC-PG507-12
 Applicable to 5 V or 12 V OC encoders
 Applicable to 5 V or 12 V push-pull encoders
 Applicable to 5 V differential encoders
24V simplified
incremental PG card
EC-PG507-24
 Applicable to 24 V OC encoders
 Applicable to 24 V push-pull encoders
 Applicable to 24 V differential encoders
IO extension card
EC-IO501-00
Programmable extension
card
EC-PC502-00
Bluetooth/WIFI
communication
card
EC-TX501/502
PROFIBUS-DP
communication card
EC-TX503
