TD350 Series VFD Dimension drawings
-340-
W1
D1
W2 W2
D2
H2H1
W4
W3
W2
W2
H4
H2
H3
Fig C.10 Flange installation diagram of VFDs of 460 V 132–200 kW
Table C.3 Flange installation dimensions of 220V 0.75–55 kW
VFD
specification
W1
W2
W3
W4
H1
H2
H3
H4
D1
D2
Installation
hole
0.7kW
150
115
130
7.5
234
220
190
16.5
185
65.5
Ø 5
1.5kW–2.2kW
170
131
150
9.5
292
276
260
10
192
79.5
Ø 6
4kW–5.5kW
191
151
174
11.5
370
351
324
15
219
113
Ø 6
7.5kW
250
210
234
12
375
356
334
10
217
108
Ø 6
11kW–15kW
275
237
259
11
445
426
404
10
242
119
Ø 7
18.5kW–30kW
270
130
261
65.5
555
540
516
17
325
167
Ø 7
37kW–55kW
325
200
317
58.5
680
661
626
23
363
182
Ø 9.5
Table C.4 Flange installation dimensions of 460 V VFDs (unit: mm)
VFD
specification
W1
W2
W3
W4
H1
H2
H3
H4
D1
D2
Installation
hole
1.5kW–2.2kW
150.2
115
130
7.5
234
220
190
13.5
185
65.5
Ø 5
4kW–5.5kW
170.2
131
150
9.5
292
276
260
10
192
78
Ø 5
7.5kW-11kW
191.2
151
174
11.5
370
351
324
15
219
113
Ø 6
15kW–18.5kW
250.2
210
234
12
375
356
334
10
217
108
Ø 6
22kW–30kW
275.2
237
259
11.5
445
426
404
10
242
118
Ø 6
37kW–55kW
270
130
261
65.5
555
540
516
17
325
167
Ø 7
75kW–110kW
325
200
317
58.5
680
661
626
23
363
182
Ø 9.5
132kW–200kW
500
180
480
60
870
850
796
37
358
178.5
Ø 11
