TD350 Series VFD Dimension drawings
-341-
C.4.3 Floor installation dimensions
W4
W2
W2
H1
H2
D1
W1
W3
D2
D2
3- ø13.0
6- ø12.0
Fig C.11 Floor installation diagram of VFDs of 460 V 220 to 315 kW
W1
W2
W2
H1
H2
3- ø22.0
D1
D2
D2
W3
6- ø12.0
Fig C.12 Floor installation diagram of VFDs of 460 V 355 to 500 kW
Table C.5 Floor installation dimensions of 460 V VFDs (unit: mm)
VFD specification
W1
W2
W3
W4
H1
H2
D1
D2
Installation
hole
220kW–315kW
750
230
714
680
1410
1390
380
150
Ø 13/12
350kW–500kW
620
230
572
-
1700
1678
560
240
Ø 22/12
