TD350 Series VFD Basic operation instructions
-43-
The keypad menu setting is shown as below.
First-level
Second-level
Third-level
Fourth-level
Parameter
setting
Func code
quick setting
/
Pxx.xx
Basic
parameter
setting
P00: Basic Function
P00.xx
P07: HMI
P07.xx
P08: EnhanceD Function
P08.xx
P11: Protection Param
P11.xx
P14: Serial Comm Func
P14.xx
P99: Factory Func
P99.xx
Motor and
encoder
parameter
setting
P02: Motor 1 Param
P02.xx
P12: Motor 2 Param
P12.xx
P20: Motor 1 Encoder
P20.xx
P24: Motor 2 Encoder
P24.xx
Control
parameter
setting
P01: Start/stop Control
P01.xx
P03: Motor 1 Vector Ctrl
P03.xx
P04: V/F Control
P04.xx
P09: PID Control
P09.xx
P10:
PLC&Mul-stepSpControl
P10.xx
P13: SM Ctrl Param
P13.xx
P21: Position Ctrl
P21.xx
P22: Spdl Positioning
P22.xx
P23: Motor 2 Vector Ctrl
P23.xx
Terminal
function
parameter
setting
P05: Input Terminals
P05.xx
P06: Output Terminals
P06.xx
P98: AI/AO Calibration
P98.xx
Optional card
parameter
setting
P15: Comm Ex-card 1
P15.xx
P16: Comm Ex-card 2
P16.xx
P25: Ex I/OCard InpFunc
P25.xx
P26: Ex I/OCard OutpFunc
P26.xx
P27: PLC Func
P27.xx
P28: Master/slave Ctrl
P28.xx
Factory
customized
parameter
setting
P90: Customized Func 1
P90.xx
P91: Customized Func 2
P91.xx
P92: Customized Func 3
P92.xx
P93: Customized Func 4
P93.xx
