TD350 Series VFD Basic operation instructions
-44-
First-level
Second-level
Third-level
Fourth-level
User defined
parameter
setting
/
/
P00.00: Speed Ctrl
…
State
parameter/fault
record
State
parameter
monitoring
P07: HMI
P07.xx
P17: State Viewing Func
P17.xx
P18: Cl-lpCtrl StateView
P18.xx
P19: Ex-card StateView
P19.xx
Fault type
record
/
P07.27: TypeofLatelyFault
P07.28: Typeof1stLast Fault
P07.29: Typeof2ndLast Fault
P07.30: Typeof3rdLast Fault
P07.31: Typeof4thLast Fault
P07.32: Typeof5thLast Fault
Fault
parameter
/
P07.33: RunFreq atLatelyFault
…
P07.56: 2ndLastFltOutpTrml
Clear fault
record
/
Confirm to clear fault record?
Modified
parameter
/
Pxx.xx: Modified parameter 1
Pxx.xx: Modified parameter 2
Pxx.xx: Modified parameter xx
Motor
parameter
autotuning
/
Confirm the motor
nameplate prm are set
correctly!
Complete parameter rotary
autoning
Complete parameter static
autoning
Partial parameter static autoning
Complete para rotary autoning2
AM
Partial para static autoning2 AM
Parameter
copy/Restore
default
memory area 1: BACKUP01
memory area 2: BACKUP02
memory area 3: BACKUP03
Restore func prm to default
Confirm restore function prm to
default value?
System setting
/
/
Language selection
Time/date
Backlight brightness control
Backlight time control
Init enable
Init setting
