TD350 Series VFD Basic operation instructions
-72-
Function
code
Name
Detailed parameter description
Default
value
P00.00
Speed control
mode
0: SVC 0 - Sensorless Vector Control mode 0
1: SVC 1 - Sensorless Vector Control mode 1
(recommended SVC mode)
2: V/F (SVPWM) - Sensorless Vector Pulse
Width Modulation
3: VC - Vector Control
Note: If 0, 1 or 3 is selected, it is required to
carry out motor parameter autotuning first.
2
P03.32
Torque control
enable
0:Disable
1:Enable
0
P03.11
Torque setting
mode selection
0: Keypad (P03.12)
1: Keypad (P03.12)
2: AI1 (100% corresponds to three times of rated
motor current)
3: AI2 (the same as above)
4: AI3 (the same as above)
5: HDIA (the same as above)
6: Set via multi-step speed (the same as above)
7: Modbus/Modbus TCP (the same as above)
8: PROFIBUS/CANopen/DeviceNet
communication (the same as above)
9: Set via Ethernet (the same as above)
10: HDIB (the same as above)
11: EtherCAT/PROFINET/Ethernet IP
12: Set via PLC
Note: Set mode 2–12, 100% corresponds to
three times of rated motor current.
0
P03.12
Torque set by
keypad
-300.0%–300.0% (rated motor current)
50.0%
P03.13
Torque reference
filter time
0.000–10.000s
0.010s
P03.14
Source of upper
limit frequency
setting of forward
rotation in torque
control
0: Keypad (P03.16)
1: AI1 (100% corresponds to max. frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: Multi-step (the same as above)
6: Modbus/Modbus TCP communication (the
same as above)
0
