Tecme NEUMOVENT - Removal of the Gas Control Set

TECHNICAL AND MAINTENANCE MANUAL
Graph VENTILATOR
Review : 04
Date:
09/05/06
53
How to Open and Close the Neumovent Graph Ventilator
Operation
Description
110
Removal of the gas control set
1- Disconnect cables 1 and 2 from the connector indicated in Fig.:11-A.
2-Remove the screws indicated in Fig.:11-A.
1 2
B
Gas
Control set
A
Screws
Conector
O
2
AIR
Back Gabinet
screws
Proportional Valves
Air and Oxigen
Regulator
Security Valve
Pneumotacograf
o
