Tecme NEUMOVENT - Sensor Calibration Details

TECHNICAL AND MAINTENANCE MANUAL
Graph VENTILATOR
Review : 04
Date:
09/05/06
76
Procedure for Initial Calibration and Setup
Neumovent Graph Ventilator
Operation
Description
70
Oxigen Valve
Do the same operations than Air va
lve.
80
Pressure Sensors
The screen will display a list of the calibration values saved in the memory which
correspond to the pressures indicated in the following table:
(zero p) (calibration p.)
(Control
Sensor) 0 100 cmH2O
(Graph
Sensor) 0 100 cmH2O
(Air
Sensor) 0 5 kg/cm2 (71 PSI)
(Ox
igen Sensor) 0 5 kg/cm2 (71 PSI)
the values on the left column, which correspond to zero pressure
Select the desired option with the
“Selection” key and press “Enter” to save the
zero
value of the four sensors
a-
Maximum value for the control sensor (right)
1-
Connect the supply pressures
2-
Select the desired option with the “Selection” key
3-
Connect a 100 cmH
2
O pressure at the outlet to the patient.
4-
Save the value with “Enter”.
Presssure Sensors
Derecho 0 0 0 Cm H
2
O
Izquierdo
0 0 0 Cm H
2
O
Aire
0 0 0 Kg./cm
2
Oxigeno 0 0 0 Kg./cm
2
