Tecme NEUMOVENT - Expiratory Valve Diagram

TECHNICAL AND MAINTENANCE MANUAL
Graph VENTILATOR
Review : 04
Date:
09/05/06
56
ASSEMBLY DETAILS
Code: 2200-A1V Name: Expiratory valve
No.
CODE
DESCRIPTION
1
2657 A1V
COMPLETE EXPIRATORY VALVE COVER
2
1111 G0V
PEEP VALVE DIAPHRAGM
3
2658 A1V
COMPLETE EXPIRATORY VALVE BODY
4
M 3x6x120 mm CRYSTAL TUBE
1
2
3
4
