Tecme NEUMOVENT - Internal Component Removal

TECHNICAL AND MAINTENANCE MANUAL
Graph VENTILATOR
Review : 04
Date:
09/05/06
50
How to Open and Close the Neumovent Graph Ventilator
Operation
Description
80
Removal of Shield
1-Remove the 5 screws indicated in Fig.:8-A.
2-Remove the shield, Fig.:8-B.
Fig.:8-B
Fig.:8-A
Shield
Front Cabinet
