TECHNICAL AND MAINTENANCE MANUAL
Graph VENTILATOR
Review : 04
Date:
09/05/06
71
Procedure for Initial Calibration and Setup
Neumovent Graph Ventilator
Operation
Description
2- If the changes in the calibration are not to be saved, press any key three times.
The next message will be displayed on the screen:
Incorrect Pasword
PRESS ANY KEY
You
will get to MENU CALIBRATION by pressing any key
20
Calibration and Setup Menu:
The calibration and setup menu displays a list in the following order:
Ajuste del reloj
Presión Ambiente
Flujo Aire
Flujo Oxigeno
Válvula Aire
Válvula Oxigeno
Sensores de Presión
Válvula PEEP
Comp. Neumo.
Entradas Analógicas
Opciones Iniciales
Numero de Serie
a-
Select the desired option with the “Selection” key
b-
Press “enter” to enter into the selected calibration screen. Then, press “Reset”
to return
to initial menu.
