TECHNICAL AND MAINTENANCE MANUAL
Graph VENTILATOR
Review : 04
Date:
09/05/06
63
ELECTRONICS DETAILS
Code: 2410-A1V Designation: CPU-Board
Without components Q:14,35 put it in the reverse position.
Optional Con3 : flat cable 20 conductors. of 70mm
