Tecme NEUMOVENT - Air Valve

TECHNICAL AND MAINTENANCE MANUAL
Graph VENTILATOR
Review : 04
Date:
09/05/06
75
Procedure for Initial Calibration and Setup
Neumovent Graph Ventilator
Operation
Description
60
Air Valve
a-
If the valve don’t have previous calibration the next message will be displayed
on the screen
:
START
SAVE
EXIT
b-
If the valve have previous calibration then press “Menú”.
c-
Select START and press “Enter” to auto calibration begins
d-
Press “Menú” and the next message will be displayed on the screen:
SAVE
EXIT
Select the desired option with the
“Selection” key and press “Enter”.
-If you select
EXIT and the values was modified; the next message will
be displayed on
the screen
:
¿Exit without save changes?
[ Enter ] Accept
[ Reset ] Cancel
Select the desired option
Then, press
“Reset”to return to initial menu.
Air valve
Target
Apertura
0.0
0.1
0
0
Memoria
Flujo
