Procedure for Initial Calibration and Setup
Neumovent Graph Ventilator
Operation
Description
b-Maximum value for the graph sensor (left)
1-
Select the desired option with the “Selection” key
2-
Connect a 100 cmH
2
O pressure at the at the P1 and P2 inlets. simultaneously with
a Y piece connection
3-
Save the value with “Enter”.
c-
Maximum value for air and oxigen sensor
1-
Select the desired option with the “Selection” key
2-
Connect an oxygen tube with a manometer at the gas inlet. Regulate a 5 kg/cm
2
(or 71 PSI) pressure.
3-
Save the value with “Enter”.
d-
Press “Menú” and the next message will be displayed on the screen:
SAVE
EXIT
Select the desired option with the
“Selection” key and press “Enter”.
-If you select
EXIT and the values was modified; the next message will be d
isplayed on
the screen
:
¿Exit without save changes?
[ Enter ] Accept
[ Reset ] Cancel
Select the desired option
Then, press
“Reset”to return to initial menu.
