TECO E310 Series User Manual

4-7
2- External terminal analog signal input function group
Function
Code No.
Description Range/Code
Factory
Setting
Remarks
02-00
AVI/ACI analog Input signal type
select
setting AVI ACI
0
0 0~10V 0~20mA
1 0~10V 4~20mA
2 2~10V 0~20mA
3 2~10V 4~20mA
02-01 AVI Signal Verification Scan 1 ~ 100(x 4ms) 50
02-02 AVI Gain (%) 0 ~1000 100 *1
02-03 AVI Bias (%) 0 ~100 0 *1
02-04 AVI Bias Selection
0 : Positive
1 : Negative
0 *1
02-05 AVI Slope
0 : Positive
1 : Negative
0 *1
02-06 ACI function Select
0 :
PID feedback signal
1 : ACI Bias signal input
0
02-07 ACI Signal Verification Scan 1 ~ 100(x 4ms ) 50
02-08 ACI Gain (%) 0 ~1000 100 *1
02-09 ACI Bias (%) 0.0 ~100.0 0.0 *1
02-10 ACI Bias Selection
0 : Positive
1 : Negative
0 *1
02-11 ACI Slope
0 : Positive
1 : Negative
0 *1
02-12 Analog Output Mode(FM+)
0 : Output Frequency
1 : Frequency Setting
2 : Output Voltage
3 : DC Bus Voltage
4 : Motor Current
0 *1
02-13 Analog Output FM+ Gain (%) 0 ~1000 100 *1
02-14 Analog Output FM+ Bias (%) 0 ~100 0 *1
02-15 FM+ Bias Selection
0 : Positive
1 : Negative
0 *1
02-16 FM+ Slope
0 : Positive
1 : Negative
0 *1
02-17
Analog Signals Fluctuation of Filter
Coefficients
1
～ 100
5
