4-6
Function
Code No.
Description Range/Code
Factory
Setting
Remarks
01-08 Up/Down keep Frequency mode
0 :
When Up/Down is used, the preset
frequency is held as the inverter stops,
and the UP/Down function is disabled.
1 : When Up/Down is used, the preset
frequency is reset to 0 Hz as the
inverter stops.
2 : When Up/Down is used, the preset
frequency is held as the inverter stops,
and the UP/Down is available
.
0
01-09 Output Relay RY1 Operation Mode 0 : Run
1 : Fault
2 : Frequency Reached
3 : Set Frequency
4 : Frequency Threshold Level
(> 1-11) - Frequency Reached
5 : Frequency Threshold Level
(< 1-11) - Frequency Reached
6 : Auto Restart
7 : Momentary AC Power Loss
8 : Emergency Stop Mode
9 :
Base Block Stop Mode
10 : Motor Overload Protection(OL1)
11 : Drive Overload Protection(OL2)
12 : PID Feedback Signal Loss
13 : Top Count Value Attained
1
01-10 Output Relay TR1 Operation Mode 0
01-11 Frequency Output Setting (Hz) 0.00 ~ 400.00 0.00 *1
01-12 Frequency Detection Range 0.00 ~ 30.00 2.00 *1
01-13 S1~ S5 switch type select
xxxx0 : S1 NO xxxx1 : S1 NC
xxx0x : S2 NO xxx1x : S2 NC
xx0xx : S3 NO xx1xx : S3 NC
x0xxx : S4 NO x1xxx : S4 NC
0xxxx : S5 NO 1xxxx : S5 NC
00000
01-14 S6 switch type select
xxxx0 : S6 NO
xxxx1 : S6 NC
00000
※ “NO”: Normal open, “NC”: Normal close.
