4-20
※Note: 1.As 3 wire control mode is selected, the terminal S1, S2 and S3 is not controlled by 01-00,
01-01 and 01-02.
2. 10-01=1, the reverse command is unavailable.
00-12
Jog Frequency
range
【1.00~25.00】Hz
00-13
Jog Acceleration Time
range
【0.1~25.5】Sec
00-14
Jog Deceleration Time
range
【0.1~25.5】Sec
When the external terminal set to the point function, and when the input signal is valid, the point
action function is executed, and the point action frequency is set by 00-12.The point movement and
deceleration time are set by 00-13/00-14 respectively.
