4-21
Group1- External terminal digital signal input function group
01- 00 Multifunction input terminals controlling S1
01- 01 Multifunction input terminals controlling S2
01- 02 Multifunction input terminals controlling S3
01- 03 Multifunction input terminals controlling S4
01- 04 Multifunction input terminals controlling S5
range
【0】:Forward/Stop Command
【1】:Reverse/Stop Command
【2】:Preset Speed unit 0 (3-02)
【3】:Preset Speed unit 1 (3-03)
【4】:Preset Speed unit 2 (3-05)
【5】:JOG Command
【6】:Emergency Stop
【7】:Base Block
【8】:Reset
【9】: Auto _ Run Mode
【10】:Speed up
【11】:Slow Down
【12】:Pulse input- Pulse width measurement (S5)
【13】:Pulse input- Frequency measurement (S5)
【14】:Up Command
【15】:Down Command
1) The terminals S1- S5 on terminal block (TM2) are multifunction input terminals. The 9 functions
shown above can be set for these terminals.
2) Function Description for 1-00~04:
A.01-00~04= 0/1(Forward/Reverse/Stop)
As forward command is ON , the inverter runs and stops when the command is OFF. The 1-00 factory
setting is forward.
As reverse command is ON, the inverter runs and stops when the command is OFF. The 1-01 factory
setting is reverse.
B.01-00~04= 2/3/4 (Frequency Command 1/2/4)
The corresponding preset frequency will be according to preset value of parameters 3-01 to 3-08 and
in relation to the operation of input terminals 1 to 3. as shown in the table below:
Output frequency preset value
Preset value =4
Preset value =3
Preset value =2
3-01
0
3-02
3-03
2
3-04
3
3-05
4
3-06
5
3-07
6
3-08
7
C.01-00~ 04=5(JOG Command)
When Jog operation, is selected, the inverter operates at the Jog acceleration and deceleration times.
The priority order of frequency: Jog Speed→Preset Speed→Keypad frequency or external
frequency signal.
D.01-00~ 04=6: External Emergency Stop
The inverter will decelerate to stop setting and Flash E.S as the emergency stop signal is received
regardless of 04-01 setting. After the emergency stop signal is removed, turn the RUN switch OFF
