Group6- Motor parameter group
06- 00
Motor Rated Voltage (VAC)
Range -
06- 01
Motor Rated Current (Amp AC)
Range -
06- 02
Motor Rated Power (kW)
Range -
06- 03
Motor Rated Speed (RPM)
Range -
06- 04
Motor Rated Frequency (Hz)
Range -
06- 05
Motor Parameter Auto Tuning
Range
【0】: Invalid
【1】: Valid
06- 06
Stator Resistance (Ohms)
Range -
06- 07
Rotor Resistance (Ohms)
Range -
06- 08
Equivalent Inductance (mH)
Range -
06- 09
Magnetizing Current (AmpsAC)
Range -
06- 10
Ferrite Loss Conductance (gm)
Range -
06- 11
Deadtime gain
Range
【0~100】
Note：Default setting 100, represents 100% compensation voltage. This coefficient can be changed to a
range of 0~100；
1）If 00-00= 1(vector mode) is selected, as power ON, set 06-05=1, the motor will not run as the
inverter performs auto tuning. Once the auto tuning is complete, the inverter will write the internal
parameter of the motor to06-06~ 06-10, and auto reset the 06-05 as 0.
2）Auto tuning must be carried out as long as the motor changed. If the internal parameters is known
already, they can be input to 06-06~06-10 directly.
Precaution
1. The motor parameter auto tuning is the stationary auto tuning. During motor auto tuning, the motor does
not rotate, and the keypad display -AT-.
2. During motor parameter auto tuning, the input signal in control circuit is invalid.
3. Before motor parameter auto tuning, please confirm the stop state of the motor.
4. The motor parameter auto tuning is only available for vector control mode (00-00=1).
