SEMI – AUTO STORAGE
While operating the "Auto Browse" function, you can press the
[MEMORY] button to store stations into memory, thereby
avoiding any unwanted stations.
In VF mode, press & hold the [VF/VM]
button. The " >> " symbol advances
from left to right and the device will
automatically browse the available
stations, staying on each station for
about 5 seconds.
To stop the auto browse function,
simply rotate the [TUNING] knob
or press on the [VF/VM] button to
confirm your desired station.
AUTO TUNING STORGARE (ATS)
1. In VF mode, fully extend the
telescopic antenna, and press the
[FM] button to select the FM band.
2. Press & hold the [FM] button.
"PRESET" flashes in the upper
right corner and the station
frequency starts running.
3. When the frequency stops running,
it means the ATS operation has
been completed; all available
stations are now stored into memory.
You can rotate the [TUNING] knob
to view all the stored stations.
MW/LW ATS:
1. Press the [AM] button to select MW or LW band.
2. Press & hold [AM] button to operate the ATS function.
11 PL-880
flashing
PAGE
PRESET
Auto browse station
Auto tuning storage (ATS) status
flashing

Other manuals for Tecsun PL-880

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Tecsun PL-880 and is the answer not in the manual?

Tecsun PL-880 Specifications

General IconGeneral
AM Frequency Range520 - 1710 kHz
LW Frequency Range100 - 519 kHz
SW Frequency Range1711 - 29999 kHz
Headphone Jack3.5 mm
Dimensions192 x 113 x 33 mm
ModesAM, FM, LW, SW
FM Frequency Range64 - 108 MHz
Tuning Steps1 kHz (AM/SW)
SelectivityFM: >60dB / AM: >40dB
Audio Output450mW
Power SupplyDC 5V
Battery LifeUp to 20 hours
Additional Featuresalarm clock, sleep timer
