To utilize the built-in charging function, connect a 5V external
power source with mini-USB plug to the device. The symbol “ ”
will advance from down to up while charging. It stops when the
battery is fully charged.
Note:
In case the device is not used for an extended period, it is
advisable to charge the included rechargeable battery once
every 3 months for about 4 hours. This will extend the battery’s
life span and keeps it in good condition.
SW ANT.
SW ANT. GAIN
DX
NORMLOCAL
DC-IN 5V LINE OUT
Connect 5V external power source with USB plug
CHARGING FUNCTION
If not functioning properly, you can reset the device by sticking a
pointed object (such as a straightened paper clip) into the reset
hole and gently press the [RESET] button.
Note:
Resetting the device will not delete
any station memories.
RESET FUNCTION
RESET button
PL-880 22
